TESYS GV2 CIRCUIT BREAKER 3P 20A-25A SCREW CLAMP

SCHNEIDER ELECTRIC



Mfr Part #: GV2ME22

Unit of Measure: PCS

The GV family of products are 3-pole, horsepower rated, UL 508 listed, manual starters. They include a manual disconnect, class 10 ambient-compensated thermal overload relay, and an instantaneous magnetic trip mechanism in one compact unit.

Description

PRODUCT OVERVIEW

Product ID 2010786
Mfr Part # GV2ME22
Supplier SCHNEIDER ELECTRIC
Class Motor protection circuit-breaker
Unit of Measure PCS
Info & Guides DataSheet

SPECIFICATIONS

Overload release current setting 20…25 A
Adjustment range undelayed short-circuit release 327…327 A
Phase failure sensitive yes
Switch off technique Thermomagnetic
Rated operating voltage 690…690 V
Rated permanent current Iu 25 A
Rated operation power at AC-3, 230 V 0 kW
Rated operation power at AC-3, 400 V 11 kW
Type of electrical connection of main circuit Screw connection
Type of control element Push button
Device construction Complete device in housing
With integrated auxiliary switch no
With integrated under voltage release no
Number of poles 3
Rated short-circuit breaking capacity lcu at 400 V, AC 100 kA
Degree of protection (IP) IP20
Height 89 mm
Width 44.5 mm
Depth 78.2 mm
